Features |
Operating system installed |
Android |
Operating system version |
9.0 |
Integrated voicemail |
Yes |
Handset type |
Wired handset |
Mounting |
Desk |
Firmware upgradeable |
Yes |
Device lock |
Yes |
Product colour |
Grey |
Base station |
Yes |
Hearing aid compatibility |
Yes |
Technical details |
Operating system installed |
Android |
Operating system version |
9.0 |
Integrated voicemail |
Yes |
Handset type |
Wired handset |
Mounting |
Desk |
Firmware upgradeable |
Yes |
Device lock |
Yes |
Speakerphone |
Yes |
Base station |
Yes |
Hearing aid compatibility |
Yes |
Harmonized System (HS) code |
85171800 |
Security |
Security algorithms |
802.1x RADIUS, HTTPS, MD5, TLS |
Design |
Product type |
IP Phone |
Handset type |
Wired handset |
Mounting |
Desk |
Device lock |
Yes |
Product colour |
Grey |
Performance |
Operating system installed |
Android |
Operating system version |
9.0 |
Hearing aid compatibility |
Yes |
Compatible products |
Microsoft Teams |
Phone features |
Message-waiting indicator (MWI) |
Yes |
Call transfer |
Yes |
Full duplex |
Yes |
Call hold |
Yes |
Call forwarding |
Yes |
Hot desking |
Yes |
Common area phone (CAP) |
Yes |
Emergency call |
Yes |
Management features |
Integrated voicemail |
Yes |
Firmware upgradeable |
Yes |
Display |
Touchscreen type |
Capacitive |
Touchscreen |
Yes |
Display resolution |
800 x 480 pixels |
Display diagonal |
10.2 cm (4″) |
Display |
LCD |
Number of simultaneous touchpoints |
5 |
Graphical user interface (GUI) language |
Multi |
Audio |
Comfort noise generation (CNG) |
Yes |
Voice codecs |
AGC, AJB, CNG, G.711a, G.711u, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, OPUS, PLC, Silk, VAD, iLBC |
Speakerphone |
Yes |
Microphone mute |
Yes |
Echo cancellation |
Yes |
Packet loss concealment (PLC) |
Yes |
Network |
Networking standards |
IEEE 802.1x, IEEE 802.3af |
Ethernet LAN interface type |
Gigabit Ethernet |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Wi-Fi |
No |
Syslog |
Yes |
Supported network protocols |
IPv4/IPv6, SNTP |
Security algorithms |
802.1x RADIUS, HTTPS, MD5, TLS |
Ethernet LAN |
Yes |
DHCP client |
Yes |
Bluetooth |
No |
Colour |
Product colour |
Grey |
Microphone |
Microphone mute |
Yes |
Ports & interfaces |
USB 2.0 ports quantity |
1 |
RJ-9 ports quantity |
2 |
Ethernet LAN (RJ-45) ports |
2 |
DC-in jack |
Yes |
Cable lock slot |
Yes |
Certificates |
Certification |
CE, FCC, RoHS, ISO 9001, CCC, REACH |
Power |
AC adapter output current |
2 A |
Energy saving mode |
Yes |
Power over Ethernet (PoE) |
Yes |
Power consumption (typical) |
5.3 W |
AC adapter output voltage |
5 V |
AC adapter input voltage |
100 – 240 V |
USB output current |
0.5 A |
Power consumption (Power over Ethernet (PoE)) |
6.8 W |
Operational conditions |
Operating temperature (T-T) |
-10 – 50 °C |
Operating relative humidity (H-H) |
10 – 95% |
Weight & dimensions |
Width |
223 mm |
Depth |
159 mm |
Height |
127 mm |
Package width |
188 mm |
Package depth |
529 mm |
Package height |
261 mm |
Packaging content |
Cables included |
LAN (RJ-45) |
Number of handles included |
1 pc(s) |
Base station |
Yes |
Stand included |
Yes |
Logistics data |
Products per master (outer) case |
5 pc(s) |
Master (outer) case width |
188 mm |
Master (outer) case gross weight |
5.3 kg |
Master (outer) case length |
261 mm |
Master (outer) case height |
529 mm |
Master (outer) case net weight |
4.8 kg |
Harmonized System (HS) code |
85171800 |
